Features
The FMT-200S digital conveyor belt metal detector can detect all types of metal contaminants, including ferrous, non-ferrous, and even difficult-to-detect stainless steel. The FMT-200S series can identify contaminants in wet, dry, hot, chilled, and frozen foods, ensuring high-quality production at the end of the line. It features high efficiency and a multilingual operating system, requiring minimal training. It supports fast automatic setup, quick product switching, and includes an auto-search program to reduce downtime. Hygienic design allows easy disassembly. The fully welded frame prevents dust accumulation in the detection head and complies with HACCP standards. All contact parts are made of food-grade materials to minimize contamination. Quick disassembly, cleaning, and reassembly help reduce downtime.
Technical Parameters
| Item | Specification |
|---|---|
| Model | FMT-200S |
| Detection Width | 200 mm |
| Detection Height | 200 mm |
| Sensitivity | Fe ≥ Φ1.2 mm Non-Fe ≥ Φ2.0 mm SUS ≥ Φ2.5 mm (Measured under no-load conditions) |
| Touch Screen | 7" TFT |
| Sensitivity Adjustment | Digital automatic adjustment |
| Alarm Mode | Alarm with automatic stop |
| Rejection Device | Optional |
| Product Memory | 99 products |
| Load Capacity | 0–10 kg |
| Conveyor Belt Width | 150 mm |
| Conveyor Speed | 0–25 m/min (adjustable) |
| Conveyor Height from Ground | 700 mm (adjustable) |
| Machine Length | 1000 mm / 1200 mm |
| Conveying Direction | Right to left |
| Machine Material | Stainless Steel 304 |
| Language | Traditional Chinese / English |
| Dimensions | 1000 × 680 × 1000 mm 1200 × 680 × 1000 mm |
| Net Weight | 155 kg |
| Power Supply | 110V / 50–60 Hz |
| Total Power | 200 W |
| Remarks | Motor: Panasonic |
